Recirculation Air Conditioning Unit With Climatic Chamber

Recirculation Air Conditioning Unit With Climatic Chamber


Recirculation Air Conditioning Unit With Climatic Chamber .
Description of Recirculation Air Conditioning Unit With Climatic Chamber for Science Lab Equipment Laboratory Instruments Manufacturers, Engineering Lab Equipments Manufacturers

Recirculation Air Conditioning Unit With Climatic Chambe is a recirculating air conditioning unit with transparent windows and a climatic chamber. Inlet air is cooled and preheated by a heater and latent heat by a humidifier before entering the climatic chamber for demonstration of climate control. The air in the climatic chamber is further heated by a heater and a humidifier before leaving. A fan after the preheater circulates the air. Part of the air leaving the climatic chamber is vented and the remaining is recirculated with make up fresh air entering the inlet duct. The amount of air recirculation is controlled by ventilation flaps. Steam generator, compressor and condenser are underneath the duct. Measuring instruments are provided for air flow rate, and temperature and humidity at various stages. Additional instruments are provided for measurement of refrigerant flow rate, temperature and pressure as well as power for the compressor and heat sources.
Experiments of Recirculation Air Conditioning Unit With Climatic Chamber
    Familiarization with recirculating air conditioning system and components.
    Determination of preheating, cooling and dehumidification, humidification, and reheating processes.
    Energy balance in the preheater, evaporator, and reheater.
    Demonstration of preheating, cooling and dehumidification, humidification, reheating, and mixing processes on psychrometric chart.
    Demonstration of refrigeration cycle on Pressure-Enthalpy diagram of the refrigerant.
    Determination of recirculating and mixing process of moist air.
    Effects of climatic chamber heat loads.
Technical Data of Recirculation Air Conditioning Unit With Climatic Chamber
Air duct : 250 x 250 mm section.
Climatic chamber : Approx 180 l.
Fan maximum airflow : 750 m3/hr.
Humidifier
Power : 3000 kW, adjustable
Preheater : 1200 W., adjustable
Reheater : 600 W., adjustable
Evaporator : 250 x 250 mm.
Compressor : 0.55 kW. (approx).
Measuring instruments
    Pressure gauges : 2 ea.
    Temperatures : 9 ea.
    Air flow rate : 2 ea., velocity sensors.
    Portable temperature / humidity meters : 3 ea. 0-50 oC, 10-90% RH.
    Refrigerant rotameter : 1 ea. 0.15-1.5 lpm.
Power measurement : Watt digital display.
Power supply : 380 V 3 Ph 50 Hz. Other power supply is available on request
